วัสดุขัดบดพรีเมียม

F54

$253.00

Purity 90% min Silicon Carbide
Industry Iron
Form Grain
Origin Domestically Produced

สรุปผลิตภัณฑ์

High-quality silicon carbide material designed for industrial applications with superior performance characteristics.

ISO Certified

ISO 9001 / 14001 / 45001

Premium Quality

Rigorous testing standards

Fast Delivery

Reliable logistics network

Expert Support

24/7 technical assistance

รายละเอียดผลิตภัณฑ์

Product Details

An industrial high-performance material, produced using high-quality quartz sand and petroleum coke, subjected to heat treatment at 2,500°C, which ensures maximum density and homogeneity of the material structure.

What Makes Us Different

Our unique manufacturing technology implies the usage of long periods of melting in large-capacity furnaces, which leads to deep crystal formation, bigger crystals, higher material purity, and reduced content of impurities. The resulting product is treated by special procedures, including chemical and water washing and an additional toughening and grindability increasing procedure.

Characteristics

  • High strength and wear-resistance for long-term operations
  • Resistance to temperature shock, radiation, and high temperatures
  • Excellent electrical and thermal conductivity
  • Homogeneity, ensuring similar quality of batches produced in industrial conditions

Where It Is Used

  • In the steelmaking industry as an effective deoxidizer and heat insulating material
  • In the abrasive industry as a base material for grinding wheels, oilstones, and other precision instruments
  • In the foundry and smelting industries for various refractory applications

Operational Efficiency

At the rate of 14 kg per ton, the material will enable the following improvements in efficiency: 15-20% less electricity used per furnace; 15-20 minutes shorter melting cycle; 8-10% higher throughput.


Micronized Particle Size Composition Comparison Table

Comparison of particle size standards across China GB-2476-83, GB/T 2481.2-1998, and Japan JISR6001-1987

China

GB-2476-83

Grade Size Range (μm)
W6363-50
W5050-40
W4040-28
W2828-20
W2020-14
W1414-10
W1010-7
W77-5
W55-3.5

China

GB/T 2481.2-1998

Grade ds50 (μm)
F23053 ± 3.0
F24044.5 ± 2.0
F28036.5 ± 1.5
F32029.2 ± 1.5
F36022.8 ± 1.5
F40017.3 ± 1.5
F50012.8 ± 1.0
F6009.3 ± 1.0
F8006.5 ± 1.0
F10004.5 ± 0.8
F12003.0 ± 0.5

Japan

JISR6001-1987

Grade ds50 (μm)
#24057.0 ± 3.0
#28048.0 ± 3.0
#32040.0 ± 2.5
#36035.0 ± 2.0
#40030.0 ± 2.0
#50025.0 ± 2.0
#60020.0 ± 1.5
#70017.0 ± 1.3
#80014.0 ± 1.0
#100011.5 ± 1.0
#12009.5 ± 0.8
#15008.0 ± 0.6
#20006.7 ± 0.6
#25005.5 ± 0.5
#30004.0 ± 0.5
#40003.0 ± 0.4
#60002.0 ± 0.4
#80001.2 ± 0.3

ต้องการข้อมูลเพิ่มเติม?

หากต้องการทราบข้อมูลเพิ่มเติมเกี่ยวกับผลิตภัณฑ์ของเรา กรุณาติดต่อเรา ตัวแทนของเราจะติดต่อกลับภายใน 24 ชั่วโมงทำการ
